Pressure |
|||||||||||||||
| Electrical Source |
Model Numbers |
Compressor Performance (LPM@BAR) |
Maximum Pressure (BAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 1.0 | 1.5 | 2.0 | 2.5 | Cintin- Uous |
Intermi- Ttent |
Rest- Art |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
| AC.50Hz | OLF75D | 40.0 | 28.3 | 25.0 | 23.3 | 20.0 | 1.4 | 2.0 | 0 | -5 | 40 | 125 | 1450 | YES | 2.5 |
| AC.60Hz | OLF75D | 48.3 | 35.0 | 30.0 | 28.3 | 25.0 | 1.4 | 2.0 | 0 | -5 | 40 | 125 | 1690 | YES | 2.5 |
| DC | OLF75D-056 | 48.3 | 35.0 | 30.0 | 28.3 | 25.0 | 2.0 | 5.0 | 2.0 | -5 | 40 | 145 | 1700 | YES | 2.8 |
|
Vacuum |
||||||||||||||
| Electrical Source |
Model Numbers |
Vacuum Performance (LPM@BAR) |
Vacuum (MBAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | -200 | -400 | -600 | -800 | MAX- IMUM |
REST- ART |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
| AC.50Hz | OLF75D | 40.0 | 25.0 | 14.2 | 7.0 | 2.0 | -880 | 0 | -5 | 40 | 125 | 1450 | YES | 2.5 |
| AC.60Hz | OLF75D | 48.3 | 31.7 | 14.7 | 7.5 | 2.2 | -880 | 0 | -5 | 40 | 100 | 1750 | YES | 2.5 |
| DC | OLF75D-056 | 48.3 | 31.7 | 14.7 | 7.5 | 2.2 | -880 | 0 | -5 | 40 | 100 | 1800 | YES | 2.8 |
