Pressure |
|||||||||||||||
Electrical Source |
Model Numbers |
Compressor Performance (LPM@BAR) |
Maximum Pressure (BAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
|||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0 | 1.0 | 1.5 | 2.0 | 2.5 | Cintin- Uous |
Intermi- Ttent |
Rest- Art |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
AC.50Hz | OLF100D | 40.0 | 28.3 | 25.0 | 23.3 | 20.0 | 1.4 | 2.0 | 0 | -5 | 40 | 130 | 1390 | YES | 3.5 |
AC.60Hz | OLF100D | 48.3 | 35.0 | 30.0 | 28.3 | 25.0 | 1.4 | 2.0 | 0 | -5 | 40 | 145 | 1690 | YES | 3.5 |
DC | OLF100D-076 | 48.3 | 35.0 | 30.0 | 28.3 | 25.0 | 2.0 | 5.0 | 2.0 | -5 | 40 | 145 | 1700 | YES | 2.8 |
OLF295D-096 | 102 | 72.0 | 50.0 | 36.0 | 23.0 | 7.0 | 8.0 | 4.0 | -5 | 40 | 370 | 1750 | YES | 6.4 | |
AC.50Hz | OLF295D | 81.7 | 65.0 | 58.3 | 53.3 | 48.3 | 2.0 | 2.5 | 0 | -5 | 40 | 300 | 1400 | YES | 6.3 |
OLF320D | 88.3 | 68.3 | 61.7 | 60.0 | 56.7 | 2.0 | 2.5 | 0 | -5 | 40 | 325 | 1400 | YES | 6.3 | |
AC.60Hz | OLF295D | 85.0 | 73.3 | 70.0 | 65.0 | 60.0 | 2.0 | 2.5 | 0 | -5 | 40 | 350 | 1690 | YES | 6.3 |
OLF320D | 98.3 | 80.0 | 75.0 | 70.0 | 63.3 | 2.0 | 2.5 | 0 | -5 | 40 | 365 | 1650 | YES | 6.3 |
Vacuum |
||||||||||||||
Electrical Source |
Model Numbers |
Vacuum Performance (LPM@BAR) |
Vacuum (MBAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0 | -200 | -400 | -600 | -800 | MAX- IMUM |
REST- ART |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
AC.50Hz | OLF100D | 40.0 | 25.0 | 14.2 | 7.0 | 2.0 | -880 | 0 | -5 | 40 | 95 | 1450 | YES | 3.5 |
AC.60Hz | OLF100D | 48.3 | 31.7 | 14.7 | 7.5 | 2.2 | -880 | 0 | -5 | 40 | 100 | 1750 | YES | 3.5 |
DC | OLF100D-076 | 48.3 | 31.7 | 14.7 | 7.5 | 2.2 | -880 | 0 | -5 | 40 | 100 | 1800 | YES | 2.8 |
OLF295D-096 | 102 | 53.0 | 29.0 | 16.0 | 9.0 | -920 | 0 | -5 | 40 | 210 | 1800 | YES | 6.3 | |
AC.50Hz | OLF295D | 81.7 | 55.0 | 36.7 | 22.0 | 7.7 | -920 | 0 | -5 | 40 | 210 | 1450 | YES | 6.3 |
OLF320D | 88.3 | 56.0 | 38.0 | 23.0 | 8.5 | -920 | 0 | -5 | 40 | 230 | 1450 | YES | 6.3 | |
AC.60Hz | OLF295D | 85.0 | 56.0 | 35.0 | 23.0 | 7.8 | -920 | 0 | -5 | 40 | 235 | 1750 | YES | 6.3 |
OLF320D | 98.5 | 65.5 | 46.0 | 26.0 | 8.8 | -920 | 0 | -5 | 40 | 255 | 1750 | YES | 6.3 |
