| Pressure | |||||||||||||||
| Electrical Source |
Model Numbers |
Compressor Performance (LPM@BAR) |
Maximum Pressure (BAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 2.0 | 4.0 | 6.0 | 8.0 | Cintin- Uous |
Intermi- Ttent |
Rest- Art |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
| AC.50Hz | OLF550D | 102 | 70 | 55 | 46.7 | 35 | 7.0 | 8.0 | 1.0 | -5 | 40 | 560 | 1380 | YES | 9.0 |
| AC.60Hz | OLF550D | 102 | 70 | 55 | 46.7 | 35 | 7.0 | 8.0 | 1.0 | -5 | 40 | 560 | 1680 | YES | 9.0 |
| DC | OLF550D-106 | 102 | 70 | 55 | 46.7 | 35 | 7.0 | 8.0 | 4.0 | -5 | 40 | 520 | 1750 | YES | 10.0 |
| AC.50Hz | OLF750D | 135 | 96.7 | 76.7 | 68.3 | 53.3 | 7.0 | 8.0 | 1.0 | -5 | 40 | 780 | 1380 | YES | 10.0 |
| AC.60Hz | OLF750D | 135 | 96.7 | 76.7 | 68.3 | 53.3 | 7.0 | 8.0 | 1.0 | -5 | 40 | 780 | 1680 | YES | 10.0 |
| TWO-GRADE Vacuum | ||||||||||||||
| Electrical Source |
Model Numbers |
Vacuum Performance (LPM@BAR) |
Vacuum (MBAR) |
Ambient Air Temp |
Power (WATTS) |
Speed (RPM) |
Thermal Protector |
Net Weight |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | -200 | -400 | -600 | -800 | MAX- IMUM |
REST- ART |
MIN. (℃) |
MAX (℃) |
(KG) | |||||
| AC.50Hz | OLF550D | 51.7 | 28.4 | 15.5 | 9.5 | 5.0 | -980 | 0 | -5 | 40 | 320 | 1450 | YES | 9.0 |
| AC.60Hz | OLF550D | 51.7 | 28.4 | 15.5 | 9.5 | 5.0 | -980 | 0 | -5 | 40 | 320 | 1750 | YES | 9.0 |
| DC | OLF550D-106 | 102.0 | 56.0 | 30.0 | 17.0 | 9.5 | -920 | 0 | -5 | 40 | 370 | 1750 | YES | 10.0 |
| AC.50Hz | OLF750D | 68.3 | 37.5 | 20.6 | 11.4 | 6.0 | -980 | 0 | -5 | 40 | 430 | 1450 | YES | 10.0 |
| AC.60Hz | OLF750D | 68.3 | 37.5 | 20.6 | 11.4 | 6.0 | -980 | 0 | -5 | 40 | 430 | 1750 | YES | 10.0 |
