| Model | Rated voltage V/Hz | Input power W |
Rated speed r/min | Nominal flow m3/h@0MPa | Maximum vacuum degree Mpa | Tank （L） | Noise dB(A) | Vibration intensity mm | Using ambient temperature ℃ |
Motor temperature rise ℃ |
Outline dimension cm | Net weight Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 550-24V | 220V/50Hz | ≤550 | ≥1400 | ≥0.102 | -0.08 | 24 | ≤58 | ≤0.45 | 0~40 | ≤40 | 55*27*53 | ≤21 |
| 750-24V | 220V/50Hz | ≤750 | ≥1400 | ≥0.135 | -0.085 | 24 | ≤62 | ≤0.45 | 0~40 | ≤50 | 55*27*53 | ≤22.5 |
| 1100-30V | 220V/50Hz | ≤220 | ≥1400 | ≥0.200 | -0.085 | 30 | ≤65 | ≤0.45 | 0~40 | ≤40 | 62*27*60 | ≤50.5 |
| 1500-40V | 220V/50Hz | ≤1500 | ≥1400 | ≥0.280 | -0.085 | 40 | ≤65 | ≤0.65 | 0~40 | ≤40 | 62*27*60 | ≤51 |
| 1500-50V | 220V/50Hz | ≤1500 | ≥1400 | ≥0.280 | -0.085 | 50 | ≤65 | ≤0.65 | 0~40 | ≤40 | 62*27*60 | ≤51 |
Remark: use 2 stage, will get higher vacuum
